6P6C RJ11 PCB Mount Connector Vertical 180 Degrees 1000V AC 50Hz 60Hz 1MIN

    Buy cheap 6P6C RJ11 PCB Mount Connector Vertical 180 Degrees 1000V AC 50Hz 60Hz 1MIN from wholesalers

    Buy cheap 6P6C RJ11 PCB Mount Connector Vertical 180 Degrees 1000V AC 50Hz 60Hz 1MIN from wholesalers
    • Buy cheap 6P6C RJ11 PCB Mount Connector Vertical 180 Degrees 1000V AC 50Hz 60Hz 1MIN from wholesalers
    • Buy cheap 6P6C RJ11 PCB Mount Connector Vertical 180 Degrees 1000V AC 50Hz 60Hz 1MIN from wholesalers

    6P6C RJ11 PCB Mount Connector Vertical 180 Degrees 1000V AC 50Hz 60Hz 1MIN

    Ask Lasest Price
    Brand Name : CSCE
    Model Number : UK YJ 001
    Certification : RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 150K pcs/day
    Delivery Time : 7-10 days
    • Product Details
    • Company Profile

    6P6C RJ11 PCB Mount Connector Vertical 180 Degrees 1000V AC 50Hz 60Hz 1MIN

    Single Port UK Jack YJ 6P6C RJ11 Telephone Jack rj11 pcb mount jack Vertical 180 degrees


    Product Description:


    Retention Strength7.7KG.F MIN Between Jack And Plug
    Withstand Voltage1000V AC 50Hz or 60Hz,1MIN.
    Storage Temperature-40℃ to +85℃
    Contact Resistance30milliohm Max
    Mating/Unmating Force2.2KG.F MAX.
    Operation Temperature-40℃ to +85℃
    Insert MaterialUL94V-0
    Operating Life600 Cycles MIN.
    Contact MaterialPhospho Bronze T=0.4mm
    Insulation Resistance500 Megohms MIN @ 500V DC.
    Current Rating1.5AMP
    Voltage Rating125 VAC RMS

    Product Drawing

    why choose us?


    100% Guarantee Quality


    ·Free samples (excluding freight charge)

    ·10 years experience for RJ45, RJ11, RJ12.4.Within a period of 12 months from the date of shipment.

    ·Manufactured Under Strict Controls.

    ·Online technical support.

    ·Factory evaluation anytime.

    ·100% Tested before shipment.


    Our advantage


    1.Short lead time: 7~10 days under 50k pcs.

    2.High quality with competitive prices.

    3.Free samples can provided.

    4.Good service to each customers.


    CSCE Connection of the principles


    >To care for health and safety of employees as corporate responsibility,all production activities must give priority to employee’s safety and health.

    >To control the production process effectively and abide by law and meet customer’s requirements.

    >Focus on customer’s normal needs, with high quality high efficiency management to provide high quality service and products.

    >Save resources,lower energy consumption. Reduce environmental pollution caused by production.

    >Abide by law.

    Continuous improvement, sustainable operation.

    Our Team


    We can turn your vision into reality. Thank you for visit. For any further information, please feel free to contact us.


    Our Services


    Customer Satisfaction:Please don't hesitate to contact us if you have any questions or concerns before or after your purchase. We are committed to your 100% satisfaction.


    Payment Terms:There are many payment methods available such as TT/LC/DP/DA/Paypal/Western Union/Money Gram


    Return Policy:If you want to exchange your items received ,you must contact us within 5 days of the receipt of your order .And you should pay additional shipping fees incurred and items returned should be kept in their original status.


    Feedback:Since your feedback is very important to our bushiness's development ,we sincerely invite you to leave positive feedback for us if you are satisfied with our products and service ,it will just take you one minute .Thanks a lot !


    Professional Certification

    • ISO 9001:2008

    • UL Certification

    • Active Environmental Policy


    Competitive Advantage:


    CSCE has various types of appearance and many kinds of internal schematic products,high quality,

    customer firstly ,100% test, 0 defect, short lead time are our best advantages.


    What's the Price?


    Some part's price is unstable according to the market, please feel free to contact us for the Latest and Best price.


    What's the Payment Method?


    1. TT/LC/DP/DA/Paypal/Western Union/Money Gram

    2. The buyer is responsible for all the shipping cost incurred.

    3. If you prefer to other payment terms, please contact us.


    CSCE Corporate Policy


    • The Corporate Goal Is To Achieve The Highest Level Of Customer Satisfaction

    Through Continuous Improvements In Quality, Delivery And Service

    • CSCE Is Committed To And Expects Quality Performance From Every Employee

    • The Company Standard Is Defect-Free Products And Services.



    Quality 6P6C RJ11 PCB Mount Connector Vertical 180 Degrees 1000V AC 50Hz 60Hz 1MIN for sale
